VICTOR 6013 Digital LC Meter Capacitance Resistance Multimeter Digital Handheld With 20000uF Display Inductance Test LCR
Main Feature
Easy and correct readout.
◇ High measuring accuracy.
◇ Measurements are possible even under a strong magnetic field.
◇ LSI-circuit provides high reliability and durability.
◇ Input overload protection is provided.
◇ LCD display for low power consumption and clear readout even in bright ambient light conditions.
◇ In-line pushbuttons allow one hand operation.
◇ Light-weight and compact construction for easy operation.
◇ Low battery condition is indicated on the LCD display.
SPECIFICATIONS
Display :LCD (Liquid Crystal Display) Max. Indication 1999.
Measurement :C (Capacitance)
Range :single 9 position, whole range value (from 0.1pF to 20000uF)
Zero Adjustment :Manual (range:±20pF)
Calibrate Adjustment :Have two internal adjustment. One is panel Zero adjustment.
Over-input :Display shows “1”.
Backlight Function: it went out by itself within 8 seconds.
Sampling Time :0~5second
Operating Temp :0℃ to 40℃.
Operating Humidity :80% MAX.R.H.
Power Supply :Single, standard 9 volt battery. NEDA 1604IEC6F22
Typical consumption current :3~4mA (RANGE:200pF-200uF)
Technical Data
| Model | 6013 |
| Range | Resolution | Max. displaying in the range | Measuring frequency | Accuracy |
| 200pF | 0.1pF | 199.9 pF | 800Hz | ±(0.5%+7) |
| 2nF | 1pF | 1.999nF | 800Hz |
| 20nF | 10pF | 19.99nF | 800Hz |
| 200nF | 100pF | 199.9nF | 800Hz |
| 2uF | 1000pF | 1.999uF | 800Hz |
| 20uF | 0.01uF | 19.99uF | 80Hz |
| 200uF | 0.1uF | 199.9uF | 8Hz |
| 2000uF | 1uF | 1999uF | 8Hz | ±(2%+5) |
| 20000uF | 10uF | 1999(×10)uF | 8Hz | ±(3%+10) |
| Features |
| Low battery indication | √ |
| Data Hold | √ |
| Backlight | √ |
| Auto power off | √ |
| Shock protection | √ |
| Sampling time | 0-5s |
| Zero Adjustment | √ |
| Operation way | Manual Range |
| Max. Display | 1999 |
| Operation Temp. & humidity | (0-40)℃; <80%RH |
